1060mm Fully Automatic Hot Stamping And Die Cutting Machine

Carton Box Die Cutting Machine Introduction

The automatic flat-bed die-cutting and hot stamping machine is a new generation of automatic flat-bed die-cutting and hot stamping machine developed by our company after years of design and innovation. Die-cutting, bronzing, creasing and cold pressing of paper cartons, cartons, and trademarks in the industry, especially various high-level and fine prints, such as cigarette boxes, wine boxes, gift boxes, small household appliances boxes, cosmetic boxes, etc. Both can be used for ordinary bronzing and embossing on this machine to obtain three-dimensional, exquisite and beautiful printed products. This machine realizes automation from paper feeding, die cutting, hot stamping, and paper delivery. It can realize the functions of automatic detection, fault display, and non-stop sampling. It also has the advantages of high die-cutting pressure and high registration accuracy. The main drive system of the machine is equipped with a pneumatic clutch and a braking device; a torque limiter (safety clutch) is installed on the main sprocket shaft; and multiple safety detection electric eyes and safety devices, etc.; can avoid the operation due to emergencies to the greatest extent The injury and equipment damage caused by the operator shall fully protect the safety of persons and equipment.


Parameter of Die Cutting Machine

Main Units

Feeder feeding unit 1.Overweight feeder paper feeding mechanism 2.The size of the processed paper can be input to the man-machine interface. After the system is calculated, the operator can automatically adjust the front and rear positions of the feeder head through the man-machine interface. 3.Fish scale paper feeder, maximum speed 125 sheets/min 4.Independent pre-coded paper mechanism, the work paper stack can be maintained at any time when stacking paper

Die cutting unit 1.Servo-controlled pressure regulating device adopts a gapless ball screw to make pressure regulating accurate and reliable 2.40Cr crankshaft 3.Worm 20Cr is ground after carburizing and quenching 4.The left and right wall panels, upper and lower platforms and bottom platforms of QT60 resin sand craft ductile iron 5.Die cutting bottom plate and knife template rotating device 6.The lubricating oil air-conditioning forced cooling lubrication system in the main transmission box
